Butterfly Valve

Sleeved Butterfly Valve – Model 9400

Design Features

Size:

2” to 48” (50mm to 1200mm)

Rating:

Class 150, PN5, PN10, PN16

Features:

Blow Out Proof Stem
Bi-directional Tight Shut-Off
Wafer, Lug & Flanged Designed

Operations:

Lever, Gear & Actuation

Reference Standards

Design:

Lever, Gear & Actuation

Face to Face :

API609 Cat-A, EN558

Drilling:

ASME B16.5, EN 1092

Testing:

API 598, EN 12266, BS 6755

Top Work:

ISO 5211

Special :

NACE MR 01-75
